Configure

Key: profile.setting.ddi.advanced.handling.on.all

Description:
Specify whether the user is granted to perform all operations on shared DDI lines which do not have the default DDI option set to yes, including
- To transfer a call which is owned by another user
- To build a conference on call which is owned by another user
- To activate MWI reception
- To set forwarding rule on the line
- To set Do Not Disturb flag

Important: Capability of making conferences with DDI calls is defined by "DDI line conference mode" value, independently of the value of "Advanced call handling on all DDI lines"

Constraint:
true|false

Related settings:
Show DDI lines in Room panel (profile.setting.room.showddilines)
DDI line conference mode (profile.setting.ddi.conference.mode)
Show Forward button in Room for DDI lines (profile.setting.room.ddiline.showforward)

Key: profile.setting.room.showddilines

Description:
Instruct the system to show shared DDI lines in the room panel. The list of shared DDI lines is presented in a dedicated tab labeled DDI Sharing Lines and includes all line registered in the user's profile. From this panel, users can invoke the call browser applet to display active calls on the selected line (one-touch on line key) or display the shared DDI line control panel (long-duration touch on line key).

Constraint:
true|false If true, DDI lines are listed and can be configured.

Related settings:
Show presence groups in Room panel (profile.setting.room.showpresence)
Show local lines in Room panel (profile.setting.room.showlocallines)
Advanced call handling on all DDI lines (profile.setting.ddi.advanced.handling.on.all)
Room panel's preferred lines (profile.setting.room.preferred.lines)
Number of last digits shown on lines in Room panel (profile.setting.room.number.last.digits)
Order lines by name (profile.setting.room.orderbyname)
Show Messaging lines in Room panel (profile.setting.room.showmessaginglines)

Key: profile.setting.room.preferred.lines

Description:
Defines which lines appear in the dedicated "Preferred Lines" tab of the Room panel.

This tab allows having a custom selection of lines, which helps focusing on a subset of lines that may be most frequently used.

Make sure each element of setting value is unique. If a line has the same extension as a profile name, the profile will be used (Priorities : Group DDI greater than Line). Good to know : if multiple lines have the same extension, only the first will be displayed (arbitrary order).

Constraint:
The (semicolon-separated) list of lines to display under the "preferred Lines" tab. Each line is either: - A standard line (DDI or not) : defined by its extension - A DDI Lines group : defined by the name of the group e.g. : 1000;2000;Group DDI 1100;3000

Related settings:
Show presence groups in Room panel (profile.setting.room.showpresence)
Show DDI lines in Room panel (profile.setting.room.showddilines)
Show local lines in Room panel (profile.setting.room.showlocallines)
Number of last digits shown on lines in Room panel (profile.setting.room.number.last.digits)

Key: profile.setting.room.mode

Description:
Defines whether the room panel is displayed in classic or in quick mode

In classic mode: when a line is not registered, it is greyed out; pressing a line entry opens the call browser applet.

In quick mode: a bullet reflects the subscription status; pressing a line switches between subscribe and monitor mode; User can subscribe and unsubscribe directly from the panel.

Constraint:
Either "classic" or "quick"

Related settings:
Show presence groups in Room panel (profile.setting.room.showpresence)
Show DDI lines in Room panel (profile.setting.room.showddilines)
Show local lines in Room panel (profile.setting.room.showlocallines)
Show Forward button in Room for local lines (profile.setting.room.line.showforward)
Show DND Forward button in Room for local lines (profile.setting.room.line.showdndforward)
Show Forward button in Room for DDI lines (profile.setting.room.ddiline.showforward)
Room panel's preferred lines (profile.setting.room.preferred.lines)
Register buttons visibility in Room panel (profile.setting.room.subscriptionbuttons.visible)
